Avante ATL328-Line Array

Avante ATL328-Line Array

The Avante Tour series ATL328 is a professional 3-way active small-format line array engineered for medium to large events and pairs nicely with the Avante ATS218 subwoofer.

Specifications

TECHNICAL DATA

  • Speaker Type: 3-Way Active, 2x8" Line Array Module, Milan certified

ACOUSTICAL DATA

  • Frequency Response:70 - 20.000 Hz
  • Max SPL One Unit: 127 dB
  • MF/HF: Coaxial 4" (MF) + 2,55" (HF) - Neodymium on custom waveguide
  • LF: 2 x 8” (2,5” voicecoil) - Neodymium
  • Crossover frequencies: 600 Hz/3,5 kHz
  • Horizontal Directivity: 110°
  • Vertical Directivity: Depends on array size and configuration

AMPLIFER:

  • Channels: 3 channels, 1 LF, 1 MF, 1 HF
  • Power: 600-Watt RMS / 1200-Watt Program / 1800-Watt Peak
  • Cooling: Convection, Internal fan
  • Power Supply: Auto switching 100V-240V, 50-60Hz
  • Protection:Thermal, DC Offset, Output Short

PROCESSOR:

  • DSP: 64-bit multimode with Milan
  • Sample Rate: 96 kHz
  • Limiter: Multi-band compressor, Peak Limiter
  • Processing (filters): FIR Linear Phase and 10-band IIR

INPUT:

  • Signal In/Out (analog):3-pin XLR
  • Power Socket: IP65 Locking Power In/Out
  • Network: Locking RJ45 In/Out for control and Milan
  • Controls: 1 x Input Attenuation (-15dB - +6dB); 1 x LF Coupling (8 presets); 1 x HF
  • Compensation (8 presets); 1 x System Test and Reset Button
  • Special Features: Frontal LED Identification System / Inclinometer

CONTSTRUCTION:

  • Housing: Multiplex plywood - Polyurea painting
  • Housing Design: Trapezoidal
  • Handles: 4 x handles (1 on each side, 2 on back)
  • Rain Cover: Included, fixed
  • Rigging Points: 3 points rigging hardware
  • Dimensions (LxWXH): 30"x18.3"x9" / 760x465x230mm
  • Weight: 64 lbs. / 28.6 kg.
$2,000.49
